The ESAB Rogue ET 201iP PRO is a 200 A high-frequency start TIG and pulse MMA welding machine weighing 9.6 kg, running on 120 or 230 V single-phase power, with TIG pulse adjustable to 500 Hz, full TIG sequence control and an IP23S housing.
Price on request. POFIS is an ESAB Authorized Distributor & Service Centre in Abu Dhabi — quotations include confirmed lead time and delivery terms.
Where it is used
Features
HF start establishes the arc without the tungsten touching the work. Scratch starting leaves tungsten inclusions in the weld, which on a food-grade or pressure application is a rejectable defect — so HF is a quality control, not a convenience.
Gas pre-flow, start current, ramp-up time, ramp-down time, finish current and post-flow are all adjustable, and can be programmed in 2-stroke or 4-stroke mode. That is the complete sequence a welding procedure specifies, rather than a simplified subset.
Pulse with background current control and frequency adjustment up to 500 Hz. High-frequency pulse constricts and stiffens the arc as well as controlling heat input — which is what gives directional control on thin material and in awkward positions.
Pulse MMA improves heat input control, minimises distortion on thin gauge material, facilitates out-of-position welding without undercut and reduces spatter. Pulsing in stick is uncommon and genuinely useful on vertical-up work.
Power factor correction ensures a stable arc resistant to power fluctuations, even on extension cables up to 100 m. On site, cable length is usually what degrades the arc, not the machine.
9.6 kg in a 403 × 153 × 264 mm robust durable housing rated IP23S, with an ergonomic handle, carrying strap and long extension cables — built for the fabrication floor and for site.
Compatible with a current-adjusting foot pedal (sold separately, W4014450), which is how a TIG welder modulates current on a changing joint without stopping.
Technical data
Published manufacturer specifications. Where a figure affects your welding procedure, confirm it against the instruction manual for your specific configuration.
| Primary voltage, 1 ph | 120–230 VAC ±15%, 50/60 Hz |
|---|---|
| Rated kVA | 7 kVA |
| Energy save mode | 50 W |
| Open circuit voltage | 78 VDC |
| Maximum output | 200 A |
|---|---|
| TIG welding output | 200 A / 18.0 V at 25% duty cycle; 129 A / 15.2 V at 60%; 100 A / 14.0 V at 100% |
| MMA welding output | 200 A / 28.0 V at 20% duty cycle; 129 A / 25.2 V at 60%; 100 A / 24.0 V at 100% |
| Current range | 10–200 A at 230 V, depending on process |
| Pulse TIG frequency | 0.2–500 Hz |
| Pulse MMA frequency | 0.2–100 Hz |
| Dimensions | 403 × 153 × 264 mm |
|---|---|
| Weight | 9.6 kg |
| Enclosure class | IP23S |
| Operating temperature | −10 °C to +40 °C |
Ordering information
Quote these part numbers on your enquiry or LPO to guarantee the exact configuration. If you are unsure which variant suits your application, send us the joint details and we will specify it.
| Description | Part number |
|---|---|
| Rogue ET 201iP PRO, CE | 0705002010 |
| Rogue ET 201iP PRO, non-CE | 0705002015 |
| Description | Part number |
|---|---|
| Rogue ES 201iP PRO — MMA and Live TIG, same chassis | 0705002009 |
| Description | Part number |
|---|---|
| Shoulder strap, Rogue | 0700500086 |
| MMA 4 hand remote current control, 10 m (33 ft) cable, 8-pin | 0700500084 |
| TXH 201F HD torch, 8-pin, air-cooled, OKC 50, 4 m | 07008SS554 |
| TXH 201F HD torch, 8-pin, air-cooled, OKC 50, 8 m | 07008SS557 |
| Exeor SR-X26-R torch, 8-pin, air-cooled, OKC 50, 4 m | 0700026254 |
| TIG foot control, 4.5 m (15 ft) cable and 8-pin connector | W4014450 |
Downloads
Need the instruction manual or spare parts list for this machine? Request it from weldiv@pofis.ae and we will send the current revision.
Frequently asked
Same chassis, same 200 A output, same dual-voltage input. The ET (0705002010) is the TIG machine — high-frequency start, full TIG sequence control and a TIG torch in the package. The ES (0705002009) leads with MMA and offers Live TIG rather than HF TIG. Choose by which process you do most.
It establishes the arc without the tungsten touching the work. Scratch starting transfers tungsten into the weld pool, and tungsten inclusions are a rejectable defect on food-grade, pressure and code work. HF start removes that failure mode entirely.
Gas pre-flow, start current, ramp-up time, ramp-down time, finish current and post-flow, all programmable in 2-stroke or 4-stroke mode. Pulse is adjustable from 0.2 to 500 Hz with background current control.
Pulsing applied to stick welding. ESAB state it improves heat input control, minimises distortion on thin material, helps avoid undercut when welding out of position, and reduces spatter. It is most useful on vertical-up work and on light gauge where a steady arc would put in too much heat.
Yes — it is stated as suitable for use with compliant generators, and PFC keeps the arc stable against power fluctuations and on extension cables up to 100 m.
At 230 V, 200 A at 18.0 V on a 25% duty cycle in TIG, 129 A at 60% and 100 A continuously at 100%. On a 120 V supply the figures are lower — see the instruction manual for those.
Yes — the package includes an SR-26 4 m TIG torch, a set of wear parts including a tungsten electrode, 3 m mains cable and plug, shoulder strap and 3 m work lead with clamp. A foot control (W4014450) is a separate order.
POFIS is an ESAB Authorized Distributor and Service Centre in Abu Dhabi. Request a quotation on this page or email weldiv@pofis.ae for price, CE variant confirmation and lead time.
Procurement & supply
The ESAB Rogue ET 201iP PRO is supplied from Abu Dhabi by Perfect Oilfield & Industrial Supply LLC as an ESAB Authorized Distributor and Service Centre. The information below covers what procurement and QA/QC departments normally need before raising a purchase order.
Stock items dispatch from Abu Dhabi within 24–48 hours. Indent items are quoted with a confirmed lead time at the time of offer.
POFIS is an approved ADNOC vendor and is listed on the approved vendor lists (AVL) of major operators and EPC contractors across the GCC. We can complete supplier registration and prequalification documentation on request.
Standard credit terms are available to registered corporate accounts. LPO, LC and advance payment are all accepted.
Delivery across the UAE and the wider GCC. Quotations can be issued on EXW, FOB, CIF or DDP terms to suit your project.
Full manufacturer warranty, honoured locally. As an ESAB Authorized Service Centre we carry out warranty work and repairs in Abu Dhabi rather than returning equipment abroad.
In-UAE service, commissioning, operator training and spare parts backing for every machine we supply.
